These machined clamps and cast clamps are used (in conjunction with a centering ring with fitted o-ring) for mating KF Flanges. The KF (QF) flange is used for through- or foreline vacuum plumbing and for simple HV chamber ports.
Hinged Clamp assemblies, detailed above, ae the most commonly used method for making KF-Flange vacuum seal connections. Assembly is simplified by the 360° rotatable flanges and self-centering feature of the centering ring.
Pressure is applied uniformly around the 15° outer surface of both flanges by finger-tightening the single wingnut until the first metal-to-metal contact is made between the spacing lips of the centering ring and the inner surface of the mating flanges. This compresses the O'ring between the flanges and makes the vacuum seal.
KF Machined/Cast Clamps Features:
• Hinged, two-part device closed with a thumbscrew or wingnut;
• Machined clamps available in stainless steel or aluminum;
• Cast clamps available in Aluminum 6061 T6
• Size: KF16~ KF50
• Vacuum range : 1×10-8 Torr
• Temperature range : 150 °C(Viton) / 80 °C(NBR)
▪ PMI test to verify material grade
▪ Dimension controlling during fabricating and finished
▪ Visual and surface 100% examination before shipment
▪ Packed in carton box firstly, then in wooden case
1. Any question and inquires will be responded within 24 hours.
2. Professional technical team support OEM/ODM service.
3. Feedback efficiently for the whole trading process.
4. 100% inspection before shipment.
5. We are a manufactor (Forging workshop and CNC machining workshop )
6. We can supply KF(NW) Vacuum Flanges & Components, ISO Vacuum Flanges & Components, CF Vacuum Flanges & Components, Flexible Bellows, Vacuum Fittings, Vacuum Valves, each products are tested well by our strictly Quality Control System.
Looking for ideal KF Vacuum Clamps
Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the KF40 Vacuum Clamps Aluminium are quality guaranteed. We are China Origin Factory of Vacuum Clamps Aluminium. If you have any question, please feel free to contact us.
